ATO Torque Transducer Applications The selection of different output signals for ATO Digital Rotary Torque Sensor ATO Rotary Torque Sensor Buying Options ATO Rotary Torque Sensor Buying Options ATO Rotary Torque Sensor Buying Options ATO Rotary Torque Sensor Buying Options Customer Reviews — — 5.0 out of 5 stars 1 5.0 out of 5 stars 1 Price — — — — Output Signal 4-20mA ±5V ±10V RS485 Capacity 0.1Nm to ±10000Nm (optional) 0.1Nm to ±10000Nm (optional) 0.1Nm to ±10000Nm (optional) 0.1Nm to ±10000Nm (optional) Power supply DC 24V DC 24V DC 24V DC 24V Non-linearity 0.1%FS 0.1%FS 0.1%FS 0.1%FS LCD Display ✔ ✔ ✔ ✔ ATO Digital Rotary Torque Sensor ATO Rotary Torque Sensor Buying Options ATO Rotary Torque Sensor Buying Options ATO Rotary Torque Sensor Buying Options ATO Rotary Torque Sensor Buying Options USB-RS485 Cable+Software Add to Cart Customer Reviews — — — — — Price — — — — $335.00$335.00 Output Signal RS485 & ±5V 0-10V RS485 & 0-10V RS485 & 4-20mA — Capacity 0.1Nm to ±10000Nm (optional) 0.1Nm to ±10000Nm (optional) 0.1Nm to ±10000Nm (optional) 0.1Nm to ±10000Nm (optional) — Power supply DC 24V DC 24V DC 24V DC 24V — Non-linearity 0.1%FS 0.1%FS 0.1%FS 0.1%FS — LCD Display ✔ ✔ ✔ ✔ ✘ USB to RS485 Cable+Software ✘ ✘ ✘ ✘ ✔ ATO Torque Transducer Meter Specification Display LCD display (show torque/speed/power value) Non-linearity 0.1%FS (Accuracy 0.001 * Capacity=Lowest Nm) Hysteresis 0.03%FS Repeatability 0.03%FS Temperature drift on zero ＜0.01%FS/℃ Temperature effect on output ＜0.01%FS/℃ Power supply DC 24V Consumption current ＜150mA Load resistance ≥2kΩ Output torque * ±5V, 0-10V, 4-20mA, RS485, RS485 & ±5V, RS485 & 0-10V, RS485 & 4-20mA Software Option* software and USB to RS485 cable is optional, if you select, you can install software on your computer (Win 8/ Win 10 system) to monitor torque data and graphs Output speed 60 pulse per revolution (OC output is standard configuration, and 5V TTL output is optional) Response performance 1kHz Signal delay 0.6ms Ultimate overload 200%FS Rated speed 10000rpm Maximum speed 15000rpm Protection grade IP43 Maximum Deformation 0.149°/1Nm at 2.60*10rad (The maximum deformation angle generated by 1Nm at 2.6*10rad rotation arc is 0.149°) Inertia moment 0.38x10-4 - 0.35x10-3 kg·cm2 Natural vibration frequency 19.4kHz Torsion constant 0.833×10Nm - 3602.7×10Nm/rad Elastic element material 17-4 stainless steel Operating temperature -10℃~+70℃ (14~158℉) Humidity 0~85%RH Electrical connection 7 pin waterproof circular connector Cable length 3m (Φ5mm) ATO Rotary Torque Transducer Sensor Dimension (unit: mm) Previous page Next page
